TransGo SK TFOD-DIESEL Shift Kit
TransGo SK TFOD-DIESEL Shift Kit
Couldn't load pickup availability
Enhance the performance of the 46RE and 47RE TorqueFlite in your 1996-2002 Dodge Ram 2500/3500 Pickup with the TransGo TFOD-Diesel SHIFT KIT. This Shift Kit allows you to modify your transmission to fix the common complaints such as TCC slip or shudder, 2nd gear band and direct clutch failure, and torque converter drain-back.
This kit gives you the internal components so your transmission can operate at higher pressures. As a result, the max line pressure in 1st,2nd,3rd, can be set to 125 PSI, and up to 150PSI in lock-up or 4th gear. These line pressure increases provide you with a significant increase in torque capacity for all of the friction elements including the TCC clutch.
Elevated line pressures are ideal for performance built and heavy-duty work trucks. Once installed the shift timing remains at the OE RPM, but are shorter and crisp wit no harshness or banging. Each kit also includes a TransGo manual valve to reduce torque converter drain back to eliminate overnight forward and reverse delay. This kit can be installed with the transmission in the truck.
Corrects/Prevents/Reduces:
TCC slip or shudder
Reduces converter drain-back
2nd band failure
3rd clutch failure
Increases TCC and clutch element torque capacity
Improves TCC engagement feel
Provides short clean shifts
Includes:
(3) High-temp low shrink sealing rings
Lower 1-2 accumulator spring
Case orifice plug
Front servo return spring
Throttle valve spring (for optional later up-shifts)
Part throttle body transfer plate, pin and two detent limit valve springs
Mumbly peg (for easy detent spring and ball installation)
USA-made hardened steel manual valve with converter charge in park provision
(3) 3-4 accumulator springs and plug for accumulator housing
Transfer plate, tapered plug, spring, checkball and limit bushing
(2) 3-4 quick fill valve springs
Main valve body separator plate
Solenoid body plate
Boost valve bracket and optional tuning plate
PR valve shim, spring seat and inner spring for line-to-converter feed provision as well as outer spring for increased pressure
(2) Drill bits
